Aerofoil Fan - Fans - China Sourcing

MODEL

Bearing Type

Rated Voltage (VDC)

Operating Voltage Range   (VDC)

Rated Current (Amp)

Rated input Power (Watt)

Rated Speed (R.P.M.)

Maximum Air Flow (CFM)

Maximum Air Pressure (mmH2O)

Noise    (dB-A)

 4010L05

Sleeve

5

4.5 to 5.5

0.10

0.50

4400

3.88

2.00

25.00

 4010L12

Fluid Dynamic

12

7 to 13.8

0.05

0.60

 4010M05

5

4.5 to 5.5

0.15

0.75

5500

4.60

3.22

28.00

 4010M12

One Ball One Sleeve

12

7 to 13.8

0.07

0.84

 4010H05

5

4.5 to 5.5

0.20

1.00

6600

5.72

4.72

35.00

 4010H12

Two Ball

12

7 to 13.8

0.09

1.08

 4010HH12

12

7 to 13.8

0.16

1.92

8000

9.23

5.56

35.00
