 DC
FAN |
|
| | |
CF7015 SERIES
| MODEL |
Bearing Type |
Rated Voltage (VDC) |
Operating Voltage Range (VDC) |
Rated Current (Amp) |
Rated input Power (Watt) |
Rated Speed (R.P.M.) |
Maximum Air Flow (CFM) |
Maximum Air Pressure (mmH2O) |
Noise (dB-A) |
|
| 7015L05 |
|
5 |
4.5 to 5.5 |
0.22 |
1.10 |
2800 |
23.38 |
2.27 |
26.50 |
| 7015L12 |
|
12 |
7 to13.8 |
0.15 |
1.80 |
| 7015L24 |
Sleeve |
24 |
14.0 to 27.6 |
0.08 |
1.92 |
| 7015M05 |
Fluid Dynamic |
5 |
4.5 to 5.5 |
0.25 |
1.25 |
3300 |
28.18 |
3.12 |
31.00 |
| 7015M12 |
12 |
7 to13.8 |
0.18 |
1.68 |
| 7015M24 |
One Ball One Sleeve |
24 |
14.0 to 27.6 |
0.10 |
2.40 |
| 7015H12 |
12 |
7 to13.8 |
0.25 |
3.00 |
3800 |
33.20 |
4.12 |
34.50 |
| 7015H24 |
Two Ball |
24 |
14.0 to 27.6 |
0.15 |
3.60 |
| 7015HH12 |
|
12 |
7 to13.8 |
0.30 |
3.60 |
4300 |
37.54 |
5.33 |
38.50 |
| 7015HH24 |
|
24 |
14.0 to 27.6 |
0.18 |
4.32 |
| * function type is optional. |
| * all readings are typical values at rated voltage. |
| * specification are subject to change without notice. |
|
