DC FAN

CS5010 SERIES

MODEL	Bearing Type	Rated Voltage (VDC)	Operating Voltage Range (VDC)	Rated Current (Amp)	Rated input Power (Watt)	Rated Speed (R.P.M.)	Maximum Air Flow (CFM)	Maximum Air Pressure (mmH2O)	Noise (dB-A)

5010L05		5	4.0~5.5	0.10	0.50	4000	1.87	3.18	22.50
5010L12		12	7.0~13.8	0.06	0.72
5010L24	Sleeve	24	14.0~27.6	0.04	0.96
5010M05	Fluid Dynamic	5	4.0~5.5	0.15	0.75	5000	2.40	5.64	28.00
5010M12		12	7.0~13.8	0.10	1.20
5010M24	One Ball One Sleeve	24	14.0~27.6	0.06	2.44
5010H12		12	7.0~13.8	0.15	1.80	6000	3.05	9.47	32.50
5010H24	Two Ball	24	14.0~27.6	0.10	2.40
5010HH12		12	7.0~13.2	0.22	2.64	7000	3.88	13.43	37.50
5010HH24		24	14.0~26.4	0.12	2.88

*function type is optional.
*all readings are typical values at rated voltage.
*specification are subject to change without notice.
